Less Power Consumable 30cbm Eto Sterilizer For Face Mask, Medical Instruments Sterilize

The ethylene oxide sterilizer is the low temperature sterilization equipment. It is a kind of use of pure ethylene oxide and ethylene oxide mixed gas at a certain temperature,pressure,humidity and-a fixed period of time, for the items enclosed in the sterilization chamber special equipment.

Application range of ethylene oxide sterilizer
1. Medical Insturments:All kinds of Face Masks, cardiac pacemaker, artificial heart, dialyzer, aspirator, oxygenator interchangeable element, automatic engineering changer, replacement line, replacement needle, artificial esophagus, artificial bone, artificial blood vessel, etc.
2. Endoscopy: laryngoscope, bronchoscope, esophageal fiberscope, mediastinoscope, cystoscope, The urethra mirror, and thoracoscopy.
3. Rubber products: gloves, finger cots, syringes, injection needles, blood collection devices, infusion sets, urine collection bags, biological hoses, nasal hoses, catheters, hoses, birth control equipment, etc.
4. Medicine: some Chinese and Western medicines, and some cosmetics.
5. Textiles and biological products: Non-woven fabric,cotton wool chemical fiber clothing, blankets, carpets, gauze, bandages, dry silk balls, cotton swabs, absorbent cotton, dressings, towels, leather, fur products, etc.
6. Cultural relics files: paper currency, tickets, medical records, files, letters, historical relics, silk satin products, animal and plant specimens, etc.
7. Instruments: electronic instruments, optical instruments, telephones, etc.
8. Hygiene products: sanitary napkins, napkins, disposable sanitary tableware, etc.

Multilingual operation panel Smart one-key operation
language can be customized according to your needs, easy to operate and the sterilization record can be automatically printed.

The material of the sterilization cabinet is 304 stainless steel.

The ethylene oxide sterilizer is composed of a sterilization box, heating system, vacuum system, dosing and gasification device, residual gas treatment system, monitoring and control system.

AYA A . The residual gas water treatment device

The residual gas is directly discharged after the water treatment deviceA A A Environmental protection and pollution-free

Installation requirements of ethylene oxide sterilizer:
1) Independent space suggest more than 12 * 5 * 3 meters (20 cubic meters) (drawings can be provided according to the actual workshop).The workshop must ensure good ventilation effect.It is recommended to have a forced air intake device and an air exhaust device inside; The air exhaust device, lights, switches, etc. need to be explosion-proof (explosion-proof grade is enough). Please refer to the drawings for workshop size, window size, air inlet and outlet size, etc. It is recommended to be in an industrial zone, away from residential areas. The workshop should be far away from the fire source. If conditions permit, there should be no fire source within 50 meters of the workshop.
2) Need to prepare the DN40 outlet hose and connect to the sewage collection port according to the actual distance on site;
3) Need to prepare DN20 hose to connect to overflow port
4) Need to prepare a water inlet hose that is consistent with the diameter of the tap (generally DN20 hose) to connect to the device according to the actual distance on site;
5) The independent space require a three-phase five-wire power distribution box and cable connecting the equipment (copper core cable, about 10 meters).
6) Each sterilizer needs an air compressor (above 4KG).
7)Need to prepare consumables (contact direct supplier or online shopping), ethylene oxide sterilization gas, ethylene oxide sterilization biological indicator agent, ethylene oxide sterilization chemical instruction card, etc.(A bottle of ethylene oxide sterilization gas and a chemical instruction card for ethylene oxide sterilization will be provided together with the device)
