Silver 3 Phase 4 Wire Ac Active Power Transducer Model:gs-ap4b1-x6ec

GS-AP4B1-x6EC series is an electrically-isolated 3phase 4wire AC active power (Watt) transducer.It measures the power in a live wire and converts it to an industrial standard output signal that is proportional to the measured input.The output signal can be 0-5 DC,0-10V DC,0-20mA DC,4-20mA DC,2.5A 2.5V DC,3A 2V DC,10A 10mA DC,12A 8mA DC etc.Processing by the advanced MCU and precisive 24-digit AD Converter inbuilt,this transducer has the advantages of high precision and superior performance; It can be connected to PLC or other data acquisition system for the purpose of industrial monitoring and control.

The input range is:voltage 20V-800V AC,current 1-30A AC.

Specifications:
* Accuracy:Class 0.5
* Power Supply:12V-24V DC;i Optionali
* Frequency:40i 75Hz
* Input:Voltage:AC 20i 800V:Current:AC 1i 30Ai Customizablei
* Voltage Resistance:a Y1Ka *V
* Output:DC 0-5V ,0-10V, 1-5V, 0-20mA, 4-20mA, 2.5A 2.5V, 3A 2V, 10A 10mA, 12A 8mAi Optionali
*Operating Temperature:-10a i +60a ;
