Golden 2516 Tm Truck

Benefiting on our huge experience and detailed knowledge in this domain, we have been able to manufacture, export and supply an array of highly qualitative 2516 TM Truck from Bhuj, Gujarat, India. This highly qualitative 2516 TM Truck is offered by us to our clients with the following specifications:

ENGINE
Model: Cummins - B5.9 180 31 - BS III
Type: DI - Turbo charged after cooled diesel engine
No of cylinders: 6 inline
Bore x stroke: 102 x 120 mm
Capacity: 5,883 cc
Max power: 117 KW (15 bhp) @ 2,500 rpm
Max torque: 590 Nm @ 1,500 rpm
Compression ratio: 18.1:1
Oil sump capacity: 15.4 ltr
Air filter: Dry type remote mounted
Oil filter: Full flow paper type
Fuel filter: Single filter with water separator
Fuel injection pump: Rotary FIP
Fuel tank: 240 ltr

GEAR BOX
Model: FS 6306 A gear box synchromesh
Speed ratios: I 9.01, II 5.27, III 3.22, IV 2.04
V 1.36, VI 1.00, reverse 8.63

WHEELS & TYRES
Rims: B7.5 x 20 10 bolts, spigotted
Tyres: Front: 10.00 X 20 16 PR, 2 Nos (highway)
Rear: 10.00 X 20 16 PR, 8 Nos (lug)
Spare: 10.00 X 20 16 PR, 1 No (highway)

PERFORMANCE (@25 000 kg)
Max speed - geared (kmph): 79
Max gradeability (running) (%): 21
Min turning circle radius (mm): 9,350

SUSPENSION
Front: Semi elliptical leaf springs span: 1,650 mm
Rear: Bell crank springs span: 1,279 mm
