Warp Beam For Water Jet Loom

We are instrumental in providing to our valuable customers excellent quality Warp Beam For Water Jet Loom which is available with following Features:-
1. Warp beam for water jet loom
2. Attractive and durable
3. Corrosion resistance
4. High accuracy

Main technical parametersi
1.Thickness of warp beam arm: 6 mm, 7 mm, 8 mm, 10 mm
2.Disc diameter: 800 mm
3.Model: 190, 210, 230, 280, 380, etc.
4. Gear: ductile iron and plain cast iron
5. Materiali The disc is made of aluminum-magnesium alloy with aging treatment, and shaft pipe is made of 20# seamless pipe.
6. Spec: Aluminum disc: 660mm-1250mm
7. Pipe spec: 180mm-460mm
8. Width: 1600mm-2600mm
9. Surface: Aluminum disc is anodized, and the pipe is painted or galvanized.
10. Flange tube body: high strength aluminum alloy material, and use the low voltage centrifugal forging, and after heat treatment, so has the best rigid and durability.
11. The function of dynamic balancei even high-speed rotating, can maintain good compatibility with knitting machine.
12. After hard machine coating processing, completely prevent corrosion and surface scratches.
Even use a few years later, also keep their durability and precision
13. It is suitable for long fiber, short fiber, industrial cloth, and glass fiber.

Clients can avail this Warp Beam For Water Jet Loom at industry leading prices from us.
