Uhf Rfid Tunnel Gate For Warehouse Automation
Price: 955 USD / Piece
Get Latest Price
Minimum Order Quantity :
5 Piece
In Stock
Product Specifications
| Dimension (L*W*H) | 371mm (L) 57mm (W) 1505mm (H) Millimeter (mm) |
| Usage | Security Purpose |
| Material | Mild Steel |
| Color | Multiple |
| Application | Office Airport, Metro Etc |
| FOB Port | SHENZHEN |
| Payment Terms | Others, Telegraphic Transfer (T/T) |
| Supply Ability | 100000 Per Year |
| Delivery Time | 30 Days |
| Sample Available | No |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | BOX |
| Main Export Market(s) | Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa |
| Main Domestic Market | All India |
Product Overview
Key Features
YND-E02A High-Performance UHF Channel Gate
The YND-E02A is a high-performance UHF channel gate designed with an advanced read-write engine, fully supporting EPCglobal C1 Gen2 ISO 18000-6C compliant RFID tags. It is widely applicable in logistics, access control, apparel, retail, warehousing, anti-counterfeiting, smart manufacturing, and other radio frequency identification systems.
Product Features
High Recognition Rate: Exceptional multi-tag reading capability with ultra-low miss-read and false-read rates.
Unique Antenna Design: Narrow horizontal beam coverage ensures precise gate detection with no blind spots.
Multi-Function Alarm: Built-in alarm lights and buzzer with sensitive and reliable triggering for alerts.
Customizable: Stylish appearance with customizable panel patterns and content.
Durability: Infrared-triggered reading significantly extends device lifespan.
Data Communication: Integrates with backend systems to provide diverse statistical insights.
Product Specifications
Physical Parameters
| Model | YND-E02A |
|---|---|
| Material | Panel: Engineering plastic; Body: Aluminum alloy |
| Appearance | Default: Beige + Silver-gray |
| Dimensions | 371mm (L) 57mm (W) 1505mm (H) |
| LED Light Bar | Default: Red/Green dual-color; Optional RGB tri-color |
| Infrared Sensors | 2 pairs |
| Installation | Tool-free slotting with stainless steel cable channels |
Performance Parameters
| Operating Frequency | 865868MHz / 902928MHz (adjustable per country/region) |
|---|---|
| Output Power | Software-adjustable (1dB step, max. 33dBm) |
| Tag Buffer Capacity | 10,000 tags (@96-bit EPC) |
| Operating Modes | Master-Slave / Standalone / Trigger Mode |
| RSSI Strength Detection | Supported |
| Power Consumption | 5W24W |
| Screen | 10.1-inch capacitive touch (1280800 resolution) |
| OS | Android 11 |
| CPU | RK3568 |
| Storage | 4GB RAM + 16GB ROM |
| Network Protocols | TCP/IP, DHCP, SSH, FTP, Telnet, UDP |
| Power Supply | Adapter: AC 100240V/5060Hz DC 12V/5A; DC input: 1224V/5A |
| Communication Protocols | RS-232, TCP/IP, Wi-Fi |
| Hardware Interface | RJ45 |
| Development Languages | C#, Java, Android |
| Reader Modes | Master-Slave / Standalone / Trigger Mode |
Environmental Parameters
| Operating Temperature | -10C to +50C |
|---|---|
| Operating Voltage | AC 220V 10% |
Company Details
Shenzhen Yukai Smart Technology Co., Ltd
YUKAI SMARTECH are a professional supplier, and focus on the design and processing of RFID tag products in China. Products include UHF/HF inlay & tag, RFID smart card, RFID adhesive label, on-metal tag, seals, clothing button, garment hang tag and other special tags etc, and can also design and produce the RFID tags with customization specification according to customer's requirement.
Our products are widely applied in: Warehousing, logistics, security, railway, tobacco management, medicine management, post, finance charges, and many other areas.
We can provide customization service. If you have any enquiry about our products, welcome to contact us!
Business Type
Exporter, Manufacturer, Distributor, Supplier, Trading Company
Employee Count
50
Establishment
2009
Working Days
Monday To Sunday
Payment Mode
Telegraphic Transfer (T/T)
