Syringe Infusion Pump - Accuracy: 100 %

Introduction :

We offer syringe pumps, which are portable & unique apparatus specially designed for neonatal, pediatric and adult patients who require superior accuracy, dependability and security when it comes to infusion therapy. It is widely used for intravenous infusion, intraarterial infusion, peritoneal medium & radiography infusion, anaesthesia infusion and chemical therapy in the different departments of hospitals. Some of the syringe pumps in different we offer are discussed as below: BYZ 810 Syringe Pump We offer ETCO2 Monitor, that is also known as Capnograph monitor, is used to measure end tidal carbon dioxide EtCO2 or ICO2 and respiration rate. Based on the state-of-art technology, this monitor can verify critical ventilation and oxygenation information in any type of clinical setting. Lightweight and portable, it is ideal for both intubated and non-intubated patients.

Features :

Freely Stackable You freely stack one onto another to provide multiple solutions, combination solutions that have a
arge
Digital LCD display: High capacity words, friendly user interface, dynamically display working status.
Positive and Negative Shuttle Debugger: Can freely regulate parameters.
Mechanism Advantage of Push-Pull Rod
Applicable to all domestic brands and all kinds of syringes.
Operable with one hand in a No-Germ environment
Alarms: Injection soon finish end of injection occlusion improperly, Installation of syringe wrong setting low battery etc.
Three Vein Infusion Modes:
Time-Volume Mode: By setting the time and injection volume, the system does the injection after automatic speed calculation.
Dosage Weight Mode: By setting the volume, weight, medicament, dosage, the system does the injection after automatic speed calculation.
Easy Speed-Setting Mode: The normal one hospitals used.
Function to remove bubbles in the tube fast.
Function to handle fast speed and large volume(bolus)
The system automatically opens up KVO after injection(reopens vein circulation)
Function to Preset Solution Volume: The user can preset solution volume. The machine will automatically stop and start KVO function once the preset solution volume is finished.
he machine automatically records the settings for last injection. It greatly reduces the workload for users.
wide range of clinical applications.
Three Power Source: AC220\50Hz, Internal Battery, 12V car ch
Syringe : Compatible with any brand.
Dimension : 280mm(L)x 210mm(W)x 130mm(H).
Technical Specification:
Injection Speed:
50(60)ml Syringe : 0.1ml/h999.9ml/h (0.1ml/h step).
30ml Syringe : 0.1ml/h900ml/h (0.1ml/h step).
20ml Syringe : 0.1ml/h600ml/h (0.1ml/h step).
10ml syringe : 0.1ml/h300ml/h (0.1ml/h step).
Purge Rate:
50(60)ml Syringe: 1500ml/h
30ml Syringe: 900ml/h
20ml Syringe: 600ml/h
10ml Syringe: 300ml/h
Bolus Rate:

50(60)ml Syringe: 1200ml/h
30ml Syringe: 720ml/h
20ml Syringe: 480ml/h
10ml Syringe: 240ml/h
Occlusion:

High 800mmHg200mmHg(106.7kPa26.7kPa)
Medium 500mmHg100mmHg(66.7kPa13.3kPa)
Low 300mmHg100mmHg(40.7kPa13.3kPa)
