1.Rotary table overview
The rotary table is the key equipment of the rotary drilling machine. In the drilling process, the well drilling can be realized by the rotation driving drill stem and drill bit of the rotary table. In the process of tripping unit and running casing, it is necessary to clip the pipe column on the rotary table to brake out a joint.

2. Function:
2.1 Function of the rotary table: the drilling tools in the rotation well transmit large enough torque and the necessary rounding speed; when running casing or tripping unit, it bears the weight of all casing strings or drill column in the well; and it completes the work of removing drill, braking out a joint, back off in the process of accident handling and bears the reaction torque.

2.2 Operation requirements of rotary table: the main bearing of the rotary table shall have sufficient strength and life in order to bear the weight of the hundreds of tons of casing strings or drill columns. It has enough lifetime under the function of the maximum axial load and axial and radial load caused by the transmission of the angular wheel when the drill column gliding; Rotary table and angular wheel can transmit large enough torque and can reverse and reliably brake; and it has good leakproofness, prevents the outside mud and mud permeating the rotary table and slows down the wear of gear and bearing.
