Conductivity And Dissolved Oxygen Meter - Black Stainless Steel, 7 Inch Capacitive Color Screen | Auto Calibration, Bluetooth Data Transfer, Ip54 Waterproof Design, Supports Multiple Parameters

For high-precision measurements of the conductivity/DO in laboratory. Widely used in the fields of biotechnology, aquaculture, power plants and environmental protection.


Main Features


a 7 inch color capacitive screen with high resolution (1024*600) and sensitivity, which can show more parameters, more intuitive and simpler to read data.

a Auto calibration, auto temperature compensation, data storage, USB data export, clock, wireless printing, function setup, smart self-diagnosis and other intelligent functions.

a English and Chinese operating system (or custom Language according to specific requirements), humanized design with adjustable screen brightness.

a Built-in big memory can store 1000 sets of test data which can be saved and transferred to USB and opened with Excel, very easy and convenient for edit.

a Auto recognition of 8 kinds of standard conductivity solutions and there are two series of standard solutions for option: USA series and China series.

a DO mode has functions of ATC, auto salinity compensation and auto pressure compensation.

a New structure polarographic DO electrode can measure temperature, salinity and dissolved oxygen simultaneously, equipped with special DO electrode calibration sleeve, only need 3~5 min for polarization.

a Combined diaphragm cap makes it extremely convenient to replace the sensitive membrane just by screwing the new cap to the electrode.

a New structure polarographic DO electrode can measure temperature, salinity and dissolved oxygen simultaneously, equipped with special DO electrode calibration sleeve, only need 3~5 min for polarization.

a Able to switch between conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.

a With standard Bluetooth module and support wireless Bluetooth printing to make operations much easier for users. Optional data transmission to PC and cell phone via Bluetooth.

a IP54 dustproof and waterproof housing.



Specifications

Conductivity

Measuring range













Resolution

Accuracy

Temp compensation

Electrode constant

Reference temperature

Conductivity:

(0.00~20.00)I S/cm (20.0~200.0)I S/cm

(200~2000)I S/cm (2.00~20.00)mS/cm

(20.0~200.0) mS/cm

(200~2000) mS/cm (K=10)

Resistivity: (0 ~ 100) MICA.cm

TDS: (0 ~ 100) g/L Salinity: (0 ~ 100) ppt

0.01/0.1/1I S/cm 0.01/0.1/1mS/cm

Electrode: A 0.5% FS, Instrument: A 0.80%FS

(0 ~ 100) a (automatic)

0.1/1/10 cm-1

25a , 20a ,18a

DO

Measuring range

Resolution

Accuracy

Response time

Residual current

Temperature compensation

Salinity compensation

Pressure compensation

Automatic calibration

Electrode type

(0 ~ 20.00) mg/L(ppm) (0 ~ 200.0)%

0.1/0.01 mg/L(ppm) 1/0.1 %

A 0.40 mg/L, A 0.3%

a 30s (25a , 90% response)

a 0.1 mg/L

(0 ~ 100)a (automatic)

(0 ~ 45) ppt (automatic)

(80 ~ 105) kPa (automatic)

Air saturated by water, water saturated by air

Polarographic

Temperature

Measuring range

Resolution

Accuracy

-10a ~ 110a

0.1a

5 ~ 60a : A 0.4a , Others: A 0.8a

Other Parameters

Data storage

Storage contents





Power

Communications

Dimensions & Weight

1000 groups

Measurement series number, measuring value, temperature, ATC or MTC status, date and time

DC12V/1A(with power adapter)

USB, Bluetooth

240A 170A 70mm/600g

Working Conditions

Ambient temperature

Ambient humidity

IP grade

5 ~ 35a

a 85%

IP54
