Optical Methane Gas Detector Cjg10/cjg100

We are engaged in exporting excellent quality Optical Methane Gas Detector CJG10/CJG100 in Jining, Shandong, China. Optical interferometric methane detector can measuring methane, carbon dioxide light gas concentration of portable instrument with high accuracy, operation and get the result quickly . Ita s used for inflammable, explosive combustible gas mixture work environment measuring methane concentration.

Application:-
It is based on optical interference principle, and it can quickly and exactly measure the concentration of the flammable and explosive mixed gases in working places.It working with high accuracy,legible
and easy to adjust and use.

Main specifications:-
Model : CJG10CJG100
Measuring range : (0~10)%(0~100)%
Tolerance : A 0.3%A 3%
Accuracy of differentiate plate : 0.5%5%
Range of dial scale : (0~1)%(0~10)%
Accuracy of dial scale : 0.02%0.2%
Bulb voltage / current : 2.5V/0.3A
Explosion protection : Exib I
Battery : 2A R20 Zn-Mn battery
Dimensions : 225A 135A 70 mm
Weight : 1.8 kg
