Louver Yxa Assembly Line With Eol And Leak Tester Voltage: 220 V Ac Volt (V)

Louver YXA Assembly Line with EOL & Leak Tester

Assembly Line Details:

Station-1: Assembly of fins No. (F1R) Assy. For verticals Fins No. 1,2,3 & 4 with Verticals Link.

Station-2: Assembly of fins No.(F2R) Assemble vertical fins with plat V Upper & Lower.

Station-3: Assembly Fixture (R) 3, 4) Assembled master fin assy. With rubber cushion, Knob stopper, stopper Plate & ornament fitting.

Station-4: Assembly assembled horizontal fins with plate-1 , 2 & LINK-H - RH.

Station-5: Assembly of Final assembled vertical fins with Case.

Station-6: Assembly Fixture (6 & 7) assembly assembled Horizontal fins with Plate - L & R

Station-7: Side Garnish-1 & 2 pressing./ FELT PESTING & Checking - RHsembly Fixture (6 & 7) assembly assembled Horizontal fins with Plate - L & R.

Station-8: Assembly Fixture 11- FOME PESTING Manually - RH

Station-9: Flow Testing (AIR) RH & LH and Assembly Fixture (L) 11 - FOME PESTING Manually LH.

Station-10: Assembly of fins No. (F1R) Assy. For verticals Fins No. 1,2,3 & 4 with Verticals Link

Station-11: (i)Side Garnish-1 & 2 pressing. / FELT PESTING & Checking - LH
(ii)Assembly Fixture ((L& R) 6 & 7) assembly assembled Horizontal fins with Plat - LH
(iii)Assembly of Final assembled vertical fins with Case - LH.

Station-12: (i)Assembly of fins No. (F1L) Assy. For verticals Fins No. 1,2,3 & 4 with Verticals Link -LH
(ii) Assembly of fins No.(F2L) Assemble vertical fins with plat V Upper & Lower -LH
(iii) Assembly Fixture (R) 3, 4) Assembled master fin assy. With rubber cushion, Knob stopper, stopper Plate & ornament fitting - LH
(iv) Assembly assembled horizontal fins with plate-1 ,2 &LINK-H - LH

Station-13: Station No. 13- EOL (L& R), for 1 unit
