Capacitor Duty Contactor - 240/440 Volt , Black Color | Excellent Damping Of Inrush Current, Enhanced Mean Lifetime Of Pfc System, Tamper-proof Resistors

Benifits Excellent damping of inrush current Improved power quality (e.g. avoidance of voltage sags) Longer useful life of main contacts of capacitor contactors Soft switching of capacitor and thus longer useful life Enhanced mean lifetime of PFC system Leading contacts with wiper function Tamper-proof and protected resistors Features Suitable for use with or without detuned reactors Largest range Weld resistence Reduce Ohmic losses Easy access for cable connections When a capacitance is switched to an AC voltage, the result is a resonant circuit damped to a greater or lesser degree. In addition to the rated current, the capacitor accepts a transient current that is a multiple of (as many as 200 times) its rated current. Fast switching, low-bounce contactors should be used. Because of the leading contacts, the inrush current spikes (reverse charging operations) are limited or damped by resistance wires. These current spikes would lead to welding of the contactora s main contacts and they are also harmful for the capacitors. Reduction of the inrush currents also avoids transients and voltage sags. Leading contacts with a wiper function are used in these capacitor contactors, i.e. each leading contact is linked to the contactor yoke by a permanent magnet. The leading contacts close before the main contacts and open when the main contacts are with certainty closed. This feature of the capacitor contactors guarantees effective, stable operation throughout useful life. The single controlled leading contacts also enhance resistance to soiling during operation. The capacitor contactors are suitable for direct switching of lowinductance and low-loss capacitor banks (IEC 831, VDE 0560) with or without detuning reactors. They feature leading auxiliary switches and damping resistors to reduce peak inrush to <70* IR (inrush current). The capacitor contactors are weldresistant up to a possible peak inrush current of 200 IR. The backup fuses gl (gG) should be scaled for 1.6 to 1.8 * IR. All capacitor contactors come with an auxiliary contact (normally open).
