Industrial Pcba - 146x102mm Black | Allwinner Arm Cortex-a53 A64 Quad Core, 1gb Ddr3, 8gb Emmc, 4k Hdmi, Onboard Wifi/bt, Dual Lvds Output

Features: * 3.5a industrial mainboard with CPU Cooler * Allwinner ARM Cortex-A53 A64 Quad Core up to 1.3GHz * Onboard 1GB DDRIII Memory and 8GB eMMC * Support single/dual LVDS Out up to 1920 x 1200, HDMI Out at 4k, 4 Lanes MIPI DSI Out * On-chip Mail400 MP2 GPU, support 4K H.264/H.265 video decoder * Onboard WiFi/BT modules, mini-PCIE for 4G option with SIM slot * Support Android6.0 Specifications: CPU : Allwinner ARM Cortex-A53 A64 Quad Core, frequency at 1.3GHz GPU : Mali400 MP2i Supports OpenGL ES 2.0 , Open VG1.1 Memory : Onboard 1GB DDR3i option 2GBi Storage : Onboard 8GB eMMC Nand Flashi option 16GBi Ethernet : 1x RJ45 LAN, 10/100Mbps 1x Mini PCIe slot with SIM Card Slot, support 3G/4G Onboard Wi-Fi/BT Module, support 802.11 b/g/n and BT4.0 Display : 1x Dual channels LVDS up to 1920*1200(30Pin header) 1x Backlight 5V/12V voltage selectioni jumperi 1x Touch screen signali I2Ci 6PIN socketi 1x 4 Lanes MIPI DSI interfacei 50PIN socket with touch screen signal, backlight control ccessi 1x HDMI Out terminal at 4k USB : 1x USB2.0 Type A, 1x OTG Type A, 4x USB2.0 Pin header UART : 4x 4-wire RS232/TTL, Pin header Audio : 1x 3.5mm Head phone slot 1x MIC Ini 2Pin headeri 1x Speaker Out (4Pin header) With 2x 20W power amplifier out, support t Left and right channels Other I/O : 1x TF Card Slot 4x GPIO via pin header 1x Buttons (Reset Button, ADC Button, Power Button) 2x LEDs (red, blue) 1x IR circuit, support infrared remote control RTC : Support Sleep/Wake up : Support Power Supply : DC-in 12V, 1x DC-in Slot, 1x 4Pin header Temperature : Operating Temperature: -20a - 60a / Humidity: 5%~95%RH, no condensation Storage Temperature: -40a - 85a / Humidity: 5%~95%RH, no condensation Dimensions(W x D) : 146 x 102mm OS : Android 6.0
