Vacuum Oven - 12x12x11" (25l), 220v 1000w, <133pa | 28 Segments Temp Control, Glass Wool Insulation, Safety Shield, Optimal Uniformity

We hold expertise in flawlessly meeting the manufacturing demands of a wide range of Vacuum Oven. Compact Vacuum Oven (12x12x11", 25 L, 250A C max) With 28 Segments Temperature Controller. Radiant warm wall heating system provides optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.
3" (7.6 cm) glass wool insulation prevents heat loss from working chamber.
Silicone door gasket and positive latch door maintain seal at all vacuum levels.
Exclusive polycarbonate safety shield protects door glass.
28 segments programmable digital temperature controller with +/- 1.5A C accuracy ( newly upgraded )
Maximum Heating Rate: 4~6 A C/min
Vacuum fittings require .25" (6.35 mm) I.D. tubing.

Specification:
Voltage: 220 V Ac
Power: 1000 W
Inner Chamber size: 300 mm x 300 mm x 275 mm ( 12 x 12 x 11", 25 Liter )
Outside size: 590 x 490 x 450 mm(24" x 20" x 18")
Vacuum : <133pa
Shipping size: 650 x 550 x 500 mm (40" x 25" x 23")
Shipping weight: 170 Lb
