Ptfe Lined Unequal Tee - High-temperature Resistance, Corrosion-resistant Design For Optimal Fluid Flow

Get Latest Price

Minimum Order Quantity :

Brand Name :

Trimurti Polymers

In Stock

Product Specifications

Coating Type	Epoxy / Painted finish
Sealing Type	PTFE Gasket / Sealing Surface
Tensile Strength	Minimum 415 MPa (Body)
Connection Type	Flanged (Drilled as per ANSI/DIN/BS)
Tolerance	A+-1 mm
Flexibility	Rigid
Yield Strength	Minimum 240 MPa (Body)
Diameter	Main run: DN25 to DN300, Branch: as per requirement
Product Type	Other, PTFE Lined Unequal Tee
Material	Other , Carbon Steel with PTFE Lining
Connection	Other, Flanged
Shape	Other, Unequal Tee
Standard	Other, ASTM, ASME B16.5 / DIN / BS
Surface Treatment	Other, PTFE Lined & Painted
Outer Diameter	DN25 to DN300
Length	As per design / requirement
Color	White (lining), Blue/Green (outer body)
Usage	Corrosive Chemical Transfer, Acid Handling Lines
Rated Pressure	Class 150 (PN10/PN16 available)
Application	other, Chemical, Pharmaceutical, Food & Beverage, Petrochemical Industries
Material Grade	ASTM A106/A105, IS 2062
Payment Terms	Cheque, Others
Delivery Time	2-3 Days
Sample Available	Yes
Sample Policy	Contact us for information regarding our sample policy
Packaging Details	Packing as per Customer requirement
Main Export Market(s)	Australia, Africa, South America, Asia, Middle East, Western Europe, Central America, North America, Eastern Europe
Main Domestic Market	Maharashtra
Certifications	ISO:9001:2008
