Hydraulic Dock Leveler - 1 Hp Power Unit, 400 Mm Vertical Travel, 5000-9000 Kg Capacity | Safe, Efficient, Easy To Operate, Durable Design

We are manufacturer of Hydraulic Dock Leveler in Gurgaon, Haryana, India which is used for loading and unloading. These dock leveler are used as a bridge between loading dock floor and load bed of transport vehicle. These are safe and efficient and work using the forklifts and pallet trucks. These are used for loading and unloading heavy loads and are able to service wide range of load bed heights. These can also work for load which are unevenly distributed.

Specifications:

Power Unit:1 HP
Loading Bay Level:1100 mm from ground
Vertical Travel:400 mm above and 300 mm below dock level
Lip Operation: Hydraulically powered lip
Length of lip extension: 400 mm from the ramp edge & 100 mm tilt compensation
Capacities: 5000 Kg to 9000 Kg

Features:

Hydraulic Operating System
Easy to operate, quite and smooth cycling
Electra-hydraulic raising & hydraulically lowering of dock leveler controller
Restricted free fall through a hydraulic velocity fuse
Power pack mounted underneath the deck

Safety Devices:

Full operating range metal toe guard protection
Hydraulic velocity fuse to restrict free fall of loaded deck
Telescopic v-grooved maintenance strut, integral to unit
