Hinges Durability Test Machine - Color: Blue And Green (Customer Requirements)

Test equipment function

Hinge test equipment is used for friction torque test and durability
test of single axis hinges and concealed hinges. It has been updated to new
generation with control and monitoring function. It is pneumatic driving and
sliding connection to eliminate additional load apply to testing hinge except
the door mass and natural effect of open and close movement. The equipment
steel frame and steel door are finely made to ensure strict mounting
requirement and easy to change different hinges

The equipment includes frame, four test doors, four sets of mounting
base plates, four sets of pneumatic driving devices, and touch screen; It does
not include general tools or test instruments (such as force meter, torque
meter, scale, stopwatch, caliper, level ruler, angle ruler, and shear device
etc.)

1)The
equipment was designed according to EN 1935.

2)Load the
test door according to hinge grade

3)Measure
initial friction torque, vertical and lateral distance.
