Hct-600-l Multi-functional Automatic Led Pick And Place Machine

With the active support of our team of experts, we are engaged in exporting, manufacturing and supplying an excellent quality collection of HCT-600-L Multi-functional Automatic LED Pick And Place Machine in Guangdong, China. Built upon the same architecture as HCT's popular automatic series of SMT machines, the HCT-600-L is specially designed for handling small electronics PCBs, with high-precision and quick turn-around times

Placement Specifications
Number of Placement Heads: 6
Maximum Placement Speed: 22,000 cph
Average Practical Placement Speed (Optimum): 15,000 cph
Placement Accuracy:+/- 0.05 (0.002")
Minimum LED Size: 1.02 mm X 0.51 mm (0.04 in X 0.02 in)
Maximum LED Size: 10 mm X 10 mm X 8 mm (0.5" X 0.5" X 0.31")
Alignment Method: Bottom vision standard
Capability for Other SMDs:
LEDs, Resistors, Capacitors, Inductors, Diodes,
Triodes, Transistors, SOTs, SOPs, QFP,s QFNs,
CSPs, IC

Board Handling Specifications
Board Handling Method: Inline Conveyor
Maximum Board Length: 400 mm (15.75") standard
Maximum Board Width: 360 mm (17.2")
Board Thickness: 0.5 mm to 3.0 mm (0.02" to 0.12")

Feeder Capacity
Feeder Type: Pneumatic
Maximum No. of Feeder Ports: 30
Tape Feeder Sizes: 8, 12, 16 and 24 mm

Physical Specifications
Overall Dimensions (L X W X H): 1300 mm X 1380 mm X 1410 mm (51.2" X 54.3" X 55.5")
Approximate Net Weight: 1000 Kg
