Coercive Force Meter

Coercive Force Meter (Steel Structure Analyzer) is designed for measuring coercive force of metal products in accordance with IEC 60404-7 and is used for non-destructive testing of chemical-thermal, thermal and thermomechanical treatments, evaluation of mechanical properties and residual stresses.

Steel structure analyzer is used for determination of mechanical properties, and measurement the hardness of metal products, as well as measurements of products of ferromagnetic alloys in the presence of correlations between the studied parameters. In addition, the device is used for testing the surface layer of ferromagnetic material for grading the metal in steel grades.

Coercive Force Meter has an electromagnet transmitter with integrated Hall sensor and removable pole tips.

The operation principle of the device consist of following: initially is performed a magnetization of area of the tested object and after that its subsequent progressive demagnetization by the increasing of the field. Next, it is the fixation of the intensity of magnetic field in accordance with the coercive force of material of tested object and measurement the amplitude of signals from the Hall sensor.

The main area of using the Coercive Force Meter (Steel Structure Analyzer) is analys the stress-strain state and residual life of pipelines, elevators, cranes and lifts, pressure vessels, steel cables of bridges also it used in engineering and metallurgical industries.

The advantage :

AcA A The probe with optional display and buttons control of the main functions

AcA A Averaging 99 results, with the possibility to use the predictive average

AcA A Real-time clock AcA A each measurement is saved with the date and time

AcA A Ability to enter additional scales and additional materials for calibration

AcA A Calibration mode of basic and additional scales

AcA A Memory: up to 100,000 measurements with the ability to view them on the screen of the device, or transfer to a PC

AcA A Adjust the brightness of the display, audio, language selection

AcA A Ability to save backups calibrations on the internal memory of the device

AcA A Smart sensors with built-in memory of calibrations
