Working principle

Unlike a suction (siphon) blasting machine, a pressure blasting machine stores the abrasive in a pressurized vessel (blast pot). When compressed air is supplied, both the air and abrasive are forced together through the blast hose, producing a faster and more powerful blast.

Step-by-step operation

1.
   Load the abrasive



   •
     Fill the pressure pot with abrasive media such as steel grit, steel shot, aluminum oxide, glass beads, or garnet.







2.
   Place the workpiece



   •
     Open the cabinet door and place the component inside.



   •
     Close and seal the cabinet to prevent abrasive leakage.







3.
   Pressurize the blast pot



   •
     An air compressor supplies compressed air (typically 58 bar or 70120 psi).



   •
     The pressure pot is sealed and pressurized.







4.
   Blast the surface



   •
     The operator presses the foot pedal or trigger.



   •
     Air carries the abrasive from the pressure pot through the blast hose to the nozzle.



   •
     The high-speed abrasive impacts the workpiece, removing rust, paint, scale, burrs, or contaminants.







5.
   Recover the abrasive



   •
     Used abrasive falls to the bottom of the cabinet.



   •
     A recovery system collects it.



   •
     Dust is removed by a dust collector.



   •
     Reusable abrasive is returned to the pressure pot or storage hopper.







6.
   Finish



   •
     Release the pedal to stop blasting.



   •
     Open the cabinet and remove the cleaned component.






Main components

•
  Blast cabinet



•
  Pressure pot (blast vessel)



•
  Air compressor



•
  Blast hose



•
  Blast nozzle



•
  Foot pedal or blast valve



•
  Abrasive recovery system



•
  Dust collector



•
  Viewing window with gloves


Process flow
Air Compressor


Pressure Pot (Abrasive)


Blast Hose


Blast Nozzle


High-Speed Abrasive


Workpiece Surface


Used Abrasive Falls Down


Recovery System + Dust Collector


Reusable Abrasive Returned
Advantages
Faster cleaning than suction blasting
Higher blasting efficiency
Uniform surface finish
Suitable for heavy rust and scale removal

Reusable abrasive lowers operating costs

Typical applications

•
  Rust and corrosion removal



•
  Paint stripping



•
  Surface preparation before painting or powder coating



•
  Deburring machined parts



•
  Cleaning castings and forgings



•
  Mold, die, and tool maintenance
