Automatic Hole Punching Machine - L1650mm*w700*h1500 , Automatic Operation With Touch Screen Control, High Precision Servo Drive, Adjustable Punching Sizes

Our company has gained name and fame in field of supplying an excellent quality range of Automatic Hole Punching Machine in Shenzhen, Guangdong, China. We offer these hole punching machines in wide range and are manufactured using high quality raw material in order to meet features like long lasting, higher efficiency and good functionality. We do quality checking before we deliver these products to our valuable clients. We offer this whole punching machine in best competitive prices.

Feature:
1.The machine is used for punching holes on IC card.
2.Adopting the touch screen, and operated by friendly interface.
3. There are two different punching sizes to the same type chip. Each mold equipped with double cylinder punching pins which can be switched easily through the touch screen to realize the different punching sizes.
4. Servo motor drive the imported ball-screw finish positioning and feeding, the parameter of each punching point is adjustable,with high precision.The whole process is simply and quickly.
5. The feeding speed of the INLAY sheet and the hole position can be changed through modifying the parameter of the servo system on the touch screen
6. The feeding and punching methods include three-molds, four-molds and five-molds, which can be selected flexibly.

Machine Spec:
1.Dimension:L1650mm*W700*H1500
2.Weight: About 300kg
3.Power supply: AC220V 50HZ
4.Power: 0.6KW
5.Compress Air: 6 kg/cm2
6.Air Consumption:20L/min
7.Control Method: Servo located + PLC
