V10 Flotect Mini Size Flow Switches

To meet particular demand of our copious customers, we are supplying and manufacturing of V10 Flotect Mini Size Flow Switches in Bengaluru ,Karnataka, India. The SERIES V10 Flotect Mini-Size Flow Switches is designed to provide inexpensive, reliable monitoring of the presence or absence of flow in a system. This series is available for field installation in pipelines from 1/2 to 2" diameter and available in brass or 303 SS body.

Product Details:
Brand : Dwyer
Wetted Material : Vane 301 SS, Body Brass or 303 SS, Pin and Magnet Ceramic 8.
Temperature : 200 Degree F (93 Degree C).
Pressure Limit : Brass body 1000 psig (69 bar), 303 SS body 2000 psig (138 bar).
Enclosure Rating : Weatherproof, meets NEMA 4X (IP66).
Electrical Connections : 18 AWG, 19" (483 mm)
Process Connection : 1/2" male NPT standard.
Switch Enclosure : Nylon
Weight : 5.5 oz (0.16 kg).

Features:
Magnetically actuated switching design gives superior performance with rugged, hermetically sealed reed switch
Simple field switch adjustment allows user to toggle between Normally Open (NO) or Normally Closed (NC) with no change in the electrical connection
Switch housing is located outside the process media, allowing simple switch changeover or maintenance without interruption of process flow
Full size, field trimmable stainless steel vane provided with removable template calibrated for brass or ductile iron reducing tees with forged steel straight tee/bushing combinations
