Ujt Characteristics - Application: Engineering Electronics Instruments
Price: 1300.0 INR / Piece
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Edutek
In Stock
Product Specifications
| Interface | 4mm banana socket terminals for external connections |
| Features | Built-in metering, sturdy trainer PCB, on-board test points, safe connection terminals |
| Output | Voltage and current measurements across UJT terminals |
| IP Rating | Not rated (indoor laboratory equipment) |
| Power Source | Mains AC Supply (230V) with internal DC adaptation |
| Components | UJT (2N2646 or equivalent), resistors, potentiometers, voltmeter, ammeter, power supply circuit |
| Operating Temperature | 0C to 50C (ambient laboratory conditions) |
| Power Supply | 230V AC, 50Hz (for trainer setup), step-down transformer to 24V DC |
| Resolution | Fine adjustment via potentiometer |
| Display Type | Other, Analog or digital meter display (dependent on model) |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Input | Variable voltage applied via potentiometer |
| Response Time | Instantaneous (with manual variation) |
| Product Type | UJT CHARACTERISTICS |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 24V DC |
| Supply Voltage | 24V DC (internal circuit), 230V AC (for trainer board) |
| Size | Standard desktop lab trainer size |
| Dimension (L*W*H) | 300mm x 200mm x 70mm (approx.) |
| Function | To study the voltage-current characteristics of a Unijunction Transistor (UJT) |
| Color | Multicolor (As per components and wiring) |
| Weight | Approx. 1.5 kg |
| Thickness | Not applicable (electronic kit) |
| Current Rating | Approx. max 50mA (through UJT circuit) |
| Capacity | Suitable for 1 experiment set-up |
| Frequency | DC operation; UJT can be used at low frequency pulse circuits |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
UJT CHARACTERISTICS
To determine the peak voltage in an UJT circuit.
To determine the valley voltage in an UJT circuit.
To calculate the intrinsic standoff ratio for an UJT.
To demonstrate the changes in peak voltage, valley voltage, and intrinsic standoff ratio when the applied voltage to an UJT circuit is changed.
To demonstrate the outputs of an UJT relaxation oscillator.
Features:
Built in regulated power supply: +15v /300 mA.
Instruction Manual: Step-By-Step detailed instruction manual.
Dimension: 27cmX 17cm X 10cm
Input Supply: 230V AC/50 Hz mains operated
