Complementary Symmetry Amplifier - Application: Engineering Electronics Instruments
Price: 1400.00 INR / Piece
(1400.0 INR + 0% GST)
Get Latest Price
In Stock
Product Specifications
| Sensors Specification | No sensors present |
| Output | Amplified Audio Output (up to several Watts) |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Color | Black, Grey (As per image reference) |
| IP Rating | Not rated |
| Input | Audio Signal Input (~mV range) |
| Display Type | Other, No Display |
| Power Supply | Dual (+VCC, -VEE or Single Supply) |
| Interface | Screw terminal blocks or solder pads for I/O |
| Response Time | Instantaneous (for analog signals) |
| Features | High efficiency, low distortion, dual channel symmetry, ease of integration in audio systems |
| Power Source | DC Power Supply |
| Operating Temperature | 0C - 70C |
| Components | Transistors (PNP & NPN), Resistors, Capacitors, Diodes |
| Thermal Conductivity | Dependent on attached heatsinks |
| Product Type | COMPLEMENTARY SYMMETRY AMPLIFIER |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | Up to 35V DC |
| Supply Voltage | 15-35V DC (typical range) |
| Size | Compact (based on PCB layout, approx. 110mm 70mm) |
| Dimension (L*W*H) | Approx. 110mm 70mm 30mm (including mounted components) |
| Function | Signal Amplification using Complementary Symmetry Configuration |
| Weight | Approx. 250g (estimated from hardware size) |
| Current Rating | Up to 2A (load dependent) |
| Thickness | PCB: Approx. 1.6 mm |
| Capacity | Output Power: 10-20 Watts (typical, with suitable load) |
| Frequency | 20Hz - 20kHz bandwidth |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
| Color | Black, Grey (As per image reference) |
| GSTIN | 0% |
Product Overview
Key Features
Company Details
Manufacturer and Exporter of all type engineering lab equipment, civil engineering lab equipment, science lab equipment, soil testing lab equipment, concrete Testing Lab Equipment, Vocational Training Equipment, Teaching lab equipment, Pharmacy Lab Equipment, Mechanical Lab for engineering college, fluid mechanic lab for engineering students, etc
Business Type
Exporter, Manufacturer, Supplier
Employee Count
25
Establishment
1973
Working Days
Monday To Saturday
GST NO
06AEWPJ6896D1ZU
Certification
AN ISO 9001:2008
