Tuned Oscillator - Application: Engineering Electronics Instruments
Price: 1200.00 INR / Piece
(1200.00 INR + 0% GST)
Get Latest Price
1 Pack Contains :
1
Minimum Pack Size :
1
In Stock
Product Specifications
| Input | AC Power Input |
| Resolution | Analog Signal |
| Color | Green |
| Features | High Stability, Portable, Durable |
| Output | Oscillating Signal |
| Power Source | Mains Powered |
| Components | Transistors, capacitors, resistors, PCB |
| Response Time | Instantaneous |
| IP Rating | IP20 |
| Power Supply | Electric |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Interface | Analog Output |
| Operating Temperature | 0C to 50C |
| Product Type | TUNED OSCILLATOR |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 220-240 V |
| Supply Voltage | 220 V AC |
| Size | Standard |
| Dimension (L*W*H) | 31 cm x 22 cm x 15 cm |
| Function | Generates stable frequency oscillations for electronic circuits |
| Weight | 2.5 kg |
| Thickness | Standard |
| Capacity | Single Channel |
| Current Rating | 0.5 A |
| Frequency | Up to 1 MHz |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | ISO 9001, 14001, CE |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
| Unit Type | Piece/Pieces |
| Packsize | 1 |
| Price | 1200.00 INR (Approx.) |
| Returnable | No |
| Stock Quantity | 5 |
| Price Type | fixed |
| Moq | 1 |
| Brand Name | EDUTEK |
| Product Unit | 1 Piece/Pieces |
| Color | Green |
| Mop | 1 |
| Currency | INR |
| Minimum Order Quantity | 1 |
| Minimum Ordered Packs | 1 |
| GSTIN | 0% |
Product Overview
Key Features
TUNED OSCILLATOR
To calculate the resonant frequency (at which there is maximum amplitude at the output).
Horizontal oscillations (to deflection yoke) results to a given input signal by parallel combination of R & C (or) L & C at the collector.
The resonant frequency is calculated by theoretical formula and verified by this experiment.
To plot the curve voltage gain versus frequency.
