Microwave Component Study Kit - Advanced Experiments With Klystron Power Supply, Magic Tee, Isolators & Couplers | Comprehensive Measurement Tools For Detector Diode And Return Loss

Microwave Component Study Kit - Advanced Experiments With Klystron Power Supply, Magic Tee, Isolators & Couplers | Comprehensive Measurement Tools For Detector Diode And Return Loss

Get Latest Price

Minimum Order Quantity :

1 Unit

Brand Name :

Edutek

In Stock

Product Specifications

Sensors Specification	Power detector, frequency meter (optional).
Resolution	Depends on measurable output, typical power meter resolution mW range.
Features	Interchangeable components, precise measurement, modular design, experiment manual included.
Power Source	Mains supply.
IP Rating	Not applicable (laboratory equipment).
Processor Speed	N/A (not microprocessor based).
Display Type	Other, Analog or digital power meter (if included).
Components	Waveguide, Klystron/ Gunn diode source, attenuator, directional coupler, circulator, slotted section, detectors, matched termination.
Response Time	Instantaneous (depends on test instrument used).
Charging Voltage	N/A (not battery powered).
Thermal Conductivity	Standard for metallic waveguide (Aluminum/Copper).
Output	RF/Microwave signal output (measurable characteristics).
Input	RF/Microwave signal input (variable frequency).
Usage	Educational laboratory experiments.
Operating Temperature	0AdegC to +50AdegC.
Power Supply	230V A+- 10% AC, 50 Hz.
Interface	BNC/SMA connectors or waveguide flanges.
Product Type	Microwave Component Study Kit.
Application	Microwave engineering, electronics, laboratory experiments.
Rated Voltage	220V AC (for associated equipment).
Supply Voltage	230V AC.
Size	Standard bench-top; varies per kit, typically 480 x 350 x 170 mm.
Dimension (LWH)	Approx. 480 x 350 x 170 mm.
Function	To study the characteristics and functioning of microwave components such as attenuators, circulators, directional couplers, and termination.
Color	Depends on component, typically metallic or black.
Weight	Approx. 5-12 kg (depending on configuration).
Current Rating	< 1A for instrument power.
Thickness	Component thickness varies; typical waveguide thickness 3-10 mm.
Capacity	Supports multiple experiments/components.
Frequency	Typically X-band, 8-12 GHz (depends on kit specification).
Payment Terms	Cash Advance (CA), Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash in Advance (CID), Cheque
Sample Available	Yes
Sample Policy	Sample costs shipping and taxes has to be paid by the buyer
Packaging Details	carton box, export quality also available
Main Export Market(s)	Middle East, Western Europe, Asia, Eastern Europe, Africa
Main Domestic Market	All India
Certifications	ISO 9001, 14001 ,CE
