Gh-cnc2208 - 2-axis Cnc Spring Machine | Max Diameter 0.8mm, Adjustable Cutting Tools, Optional Torsion Device, High Speed Production At 500rpm

GH-CNC2208 machine is a two-axis cnc spring machine consisting of wire feeding axis and cam axis. The two axes can work independently or synchronously by means of the program. The space, outside diameter and cutting tools are driven by the cam motor. The wire feeding is driven by independent feeding motor;


1.The cutting tools can be adjusted by the cabinet's inside and outside easily and quickly;
2.This machine can manufacture various compression springs, oil seal springs, battery springs etc;
3.Optional accessories:
Torsion device, oil seal device, prize-up device, length gauge.



Purchase guidance:

GH-CNC2208 high speed compression spring machine;
GH-CNC2208L torsion and compression spring machine;
GH-CNC2208Y oil seal compression spring machine.



Technical paremeters for 2-axis cnc compression spring machine GH-CNC2208:



ModelGH-CNC2208
Axis2 Axis
Diameter0.15~0.8mm
Max Feeding Dia 20mm
Max Feeding Length unlimited
Max production speed 500RPM
Probe2set
Cam Servo Motor 1.0kw
Wire Feed Servo Motor 1.0kw
Power AC three-phase 220V
Dimension870 X 780 X 1600mm
Weight350kg
