Heavy Duty Shaping Machine - Alloy Steel, 1730x940x1550 Mm | Sturdy, Universal Table, Precise Operation, Easy Maintenance
Get Latest Price
In Stock
Product Specifications
| Stroke Length | 610 Mm |
| Ram Length | 1041 Mm |
| Ram Bearing | 736*255 Mm |
| Table Surface | 495*318 Mm |
| Max. Table Travel | 610 Mm |
| Motor | 2 Hp |
| Dimensions | 1730*940*1550 Mm |
| Features | Sturdy Construction, Universal Table, Alloy Steel Components, Precise Operation, Easy Maintenance, Durable, Accurate Shaping, High Efficiency, Cost Effective |
| GSTIN | 0% |
Product Overview
Key Features
Owing to our vast knowledge in this domain, we have gained expertise in offering Heavy Duty Shaping machine. Offered machine is designed and manufactured at our vendorsA' end in compliance with international standards using high functionality components and allied methodology. Provided machine is widely used to produce products into different shapes such as curves, angles and others. Clients can avail this Heavy Duty Shaping machine from us at cost-effective price within promised time-frame.
Features
Sturdy construciton to ensure vibration free and silent working
Universal table with support and swival base vise
All highly stressed components are manufactured from alloy steel.
Ram alignemnt is possible with taper jib strip
Centrally operated drip type self lubricating system
Possible to operate tool slide in 90 degree either side
Scrapping and lapping are followed to obtain more precision work and accuracy
Housing bushes are manufactured from selected gun metal to extend long trouble free service
Sturdy helical gears with taper jib strip
All the components are tested in QC depeartment to give complete interchangeability.
Setting of belt is done from back side with ease and without and hindrance
Accuracy Grade-1
Technical Specifications
| Particulars | mm | Inch |
| Length of stroke | 610 | 24 |
| Length of Ram | 1041 | 41 |
| Length & Width of Ram bearing | 736*255 | 29*10 |
| Max & Min distance from table to Ram | 457*77 | 18*3 |
| Working Surface of table | 495*318 | 19.5*12.5 |
| Maximum table travel horizontal | 610 | 24 |
| Maximum table travel vertical | 430 | 17 |
| Angular movement of table on either side | 90L ; 90R | |
| Max vertical travel of tool slide | 178 | 7 |
| Max Swivel of tool head | 90L ; 90R | |
| Range of ram Speed | 4 speed | |
| Legth and width of base | 1320*483 | 52*19 |
| Range of tool head feed | Hand feed | |
| Main drive motor (3 Phase) | 2 H.P.(960 rpm) | |
| V-Belt section | B-57 | |
| Main switch starter(Push Button type) | 5 AMP Mini Dol Starter | |
| Overall Dimension | 1730*940*1550 | 68*43*61 |
Company Details
Focusing on a customer-centric approach, J. R. RAO & CO. has a pan-India presence and caters to a huge consumer base throughout the country. Buy Machinery & Parts in bulk from J. R. RAO & CO. at Trade India quality-assured products.
Business Type
Exporter, Supplier, Trading Company
Employee Count
12
Establishment
1989
Working Days
Monday To Sunday
GST NO
29AAHPR6144H1ZC
Payment Mode
Online Payments (NEFT/RTGS/IMPS), Cheque/DD
