Fuel Transfer Motor - Cast Iron, Displacement 78-393 Cmâ³/rev, Torque 235-638 Nm, 7.8-30.9 Mpa Pressure, Efficient Transfer And Precise Control

Authorized in the market as one of the trustworthy trader and supplier a wide assortment of Fuel Transfer Motor in Pan India. This range of Fuel Transfer Motor is designed and made employing finest grade raw material and cutting-edge techniques under the supervision of trained professionals as per the set industry standards. These are offered with us at most competitive rates in the market.

ORB-A
Specifications
Item / Model A-080 A-100 A-125 A-160 A-200 A-250 A-290 A-315 A-390
Theoretical Displacement (cm3/rev) 78 97 123 158 195 244 288 306 393
Normal Continuous Revolution (min-1) 850 690 550 430 350 280 250 230 190
Max. Revolution (min-1) 850 850 690 540 440 350 300 280 230
Normal Continuous Torque (Nm) 235 284 324 334 373 373 422 432 441
Max. Instantaneous Torque (Nm) 343 383 392 471 520 579 608 608 638
Normal Continuous Pressure (P MPa) 20.6 20.6 18.1 14.7 13.2 10.8 10.3 9.8 7.8
Max. Instantaneous Pressure (P MPa) 30.9 27.4 22.1 20.6 18.6 16.7 14.7 13.7 11.3
Permissible Back Pressure (MPa) 6.9
Approx. Weight (kg) 10.1 10.3 10.6 10.9 11.1 11.8 12.2 12.4 13.2
