Flow Through An Orifice Apparatus - Clear Acrylic Cylinder With Adjustable Constant Head, Wire Mesh Discharge Head, Jet Measurement Capabilities
Price: 100 INR / Piece
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Teknik
In Stock
Product Specifications
| Number of Specimens | Single specimen at a time |
| Max Height | Approx. 700 mm |
| Display Type | Direct visual scale/manometer |
| Test Range | Typically 0.25 to 1 lps (depending on orifice) |
| Measuring Range | Head: 0-250 mm |
| Port Size | 3/8 inch BSP |
| Usage | Fluid Machines Equipments |
| Humidity | Up to 85% RH (non-condensing) |
| Interface Type | Manual measurement |
| Response Time | Immediate |
| Power Supply | 230 V AC, 50 Hz |
| Temperature | Ambient (5AdegC aEUR" 40AdegC) |
| Accuracy | A+-1% of full scale |
| Resolution | 1 mm (manometer head) |
| Product Type | Flow through an Orifice Apparatus |
| Features | Transparent tank, interchangeable orifice plates, durable construction |
| Frequency | 50 Hz |
| Operating Voltage | 230 V AC |
| Equipment Type | Flow through an Orifice Apparatus |
| Application | Fluid Machines Equipments |
| Mounting Type | Table top |
| Automation Grade | Manual |
| Capacity | Tank capacity approx. 40 L |
| Machine Weight | Approx. 25 kg |
| Control Mode | Manual operation |
| Supply Ability | 100 Per Week |
| Delivery Time | 1 Week |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
Flow through an Orifice Apparatus
To be used with Hydraulics Bench. For measurement of contraction and velocity and discharge coefficients for orifice discharge. Clear acrylic cylinder with adjustable constant head. Water admittance via wire mesh discharge head. Orifice at the bottom of the cylinder. Traverse assembly below the cylinder, with wire and pitot tube. The wire measures jet diameter, pitot tube measures jet velocity. Velocity head on pitot tube and total head are indicated on manometer tubes.
To be used with Hydraulics Bench. For measurement of contraction and velocity and discharge coefficients for orifice discharge. Clear acrylic cylinder with adjustable constant head. Water admittance via wire mesh discharge head. Orifice at the bottom of the cylinder. Traverse assembly below the cylinder, with wire and pitot tube. The wire measures jet diameter, pitot tube measures jet velocity. Velocity head on pitot tube and total head are indicated on manometer tubes.
