Flow Over Weirs Apparatus - Stainless Steel, 190.5mm Height, 178mm Width | Features: Sharp-crested V-notch & Rectangular Weir, 0.1mm Accuracy
Price: 1400.0 INR / Unit
Get Latest Price
Minimum Order Quantity :
1 Unit
Brand Name :
Teknik
In Stock
Product Specifications
| Equipment Type | Flow Over Weirs Apparatus |
| Usage | Fluid Machines Equipments |
| Humidity | Up to 85% RH (Non-condensing) |
| Features | Corrosion-resistant channel, easy weir plate interchangeability, robust frame |
| Display Type | Manual scale/Pointer |
| Frequency | 50 Hz |
| Response Time | Immediate manual reading |
| Automation Grade | Manual |
| Product Type | Flow Over Weirs Apparatus |
| Port Size | Inlet & outlet: 12 mm |
| Temperature | Ambient (10AdegC to 40AdegC) |
| Operating Voltage | 230 V AC |
| Resolution | 1 mm |
| Measuring Range | 0-300 mm water head |
| Application | Fluid Machines Equipments |
| Max Height | 500 mm (apparatus height) |
| Accuracy | A+-1 mm |
| Test Range | Varies with head over weir |
| Power Supply | 230 V AC, 50 Hz |
| Mounting Type | Table Top |
| Capacity | Water tank capacity: 30 Litres |
| Machine Weight | Approx. 35 kg |
| Test Width | Channel width: 100 mm |
| Control Mode | Manual |
| Payment Terms | Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA) |
| Supply Ability | 100 Per Day |
| Delivery Time | 1 Week |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
Introduction of Flow over weirs apparatus
A weir is an overflow structure extending across a stream or a channel and normal to the direction of the flow. They are normally categorized by their shape as either sharp-crested or broad-crested. This laboratory experiment focuses on sharp-crested weirs only. Two different types of weirs will be introduced:
1- The V-notch weir.
2- The rectangular weir (horizontal weir with end contractions).
Objective: To Study the Discharge over different type of notches.
Specification of Flow over weirs apparatus:
Dimensions of rectangular notch: Height=82mm, width=30mm.
Angle of V notch weir: 900 inclusive.
Hook and point gauge range: 0 to 150mm.
Accuracy: 0.1mm.
Overall dimension of weir plates: Height=190.5mm, Width=178mm, Thickness=4mm.
