Fiber Ball Pillow Machine

With our dedicated teams, we are engaged in Exporter & Manufacturer of Fiber Ball Pillow Machine in Lishui, Zhejiang, China, This equipment is a roll the chemical fibre into pearl-sized fiber balls, and filling the pillows. There are loosening parts inside, so the chemical fibre need not to be loosened in advance. Have good adaptability to such various kinds of chemical fibre. China--patented technologies have been uniquely applied in this machine.

Specification
3 Operated by 2 person, it can be fed and discharged continuously with stable output. The output is 50-80 kilograms per hour.

4 Fiber ball tightness and size can be adjusted, but the shape is mainly determined by the varieties of fiber properties.

5 The chemical fiber must be 3-dimensionally curled, silicon added

polyester fiber of 4D a 15D and 51-64 mm. Usually. 7D*51mm ,15D*64mm is adopted.

6. The pillow filling machine is simple to operate, fast in filling speed, small in the sealing gap and the pillow core is compacted when it is filled.

7. The machine is equipped with a T- shaped filling pipe, with 2 filling outlets which can be used in turn for continuous filling of into pillow cores. Filling pipes of N 38 mm or 90 mm can be provided according to customera s requests

8. The motor 7.7 KW , is provided with a power source switch box.
