Electrical Isolation Transformer By Servo Technologies System

Application:
Protect the CNC Machines, Computer and Telecommunications
Equipment from damage due to electrical Noise, Spikes etc.
Where ground potential of system units are different horn each other and are exposed to the effects of instability at high frequencies.
Where ground of the equipment cannot be earthed.
When no slightest current leakage is permitted in the equipment, especially for computers and CNC controls where only less than 100 micro AMPS is only permitted.
To protect against strong lighting, impulse noise, bus short- circuit, accidental discharge of capacitors etc. When no slightest current leakage is permitted in the equipment.
To shield large number of electronic equipment which individually also are producing different type of electrical noise at a common busbar typically CNC machines, drives, hardening equipment etc.

Specifications:

Power: 5 kVA
Type of Isolation Transformers: Power Line Isolation Transformer
Cooling Type: Dry type/Air cooled
Phase: 3 Phase
Ratios: 1.1 and 2:1
Insulation Resistance: More than 1000 mega ohms.
Coupling Capacitance: 0.1 PF for 100 db
Leakage Current: Less than 20 Micro Amps
Common Model Attenuation: 100 db
Regulation: Better than 3.5%
Di-electric strength: 2500 V AC for 120 sec
