Edm Machine, Model-f35

We are exporter, manufacture and supplier of this EDM Machine in Pune, Maharashtra, India. Product Details: Minimum Order Quantity :1 Unit Model :F35 Brand :Fostex Machine Floor Area :1500x1200 mm Filteration Vertical :10-2 Nos Max Workplace Weight :305 kg Work Tank :800x500x325 mm Work Table :550x350 mm X Travel :300 mm Y Travel :200 mm Z Travel :200 mm Daylight :300 mm (with Electrode Holder) Shut Height :95 mm Pump Motor :0.5 hp Die Electric Tank :170 L Net Weight :1050 kg We are offering EDM Machine that comes with two-part design and low working height. Manufactured in accordance with the preset industry guidelines, these electric discharge machining machines are quite durable and exhibit supreme ruggedness. EDM machines offered by us are provided in tamper proof packaging to prevent damages. Features: Compact design that needs minimal floor space Cast iron machine tool body to ensure high rigidity Low working height for easy loading/ unloading of workpiece Ball screw for X and Y axis providing highest repeatability in travel In-built filtration tank for efficient filtration Double door opening to provide ease in lob alignment Best sparking conditions and maximum life for dielectric with Two Vertical filters of 10 microns for filtration Specifications: Mechanical Unit Unit F Series F-Plus Series Machine Tool mm F35 F50 F65 F50 plus F65 plus My Edm Work Tank mm 800x500x325 900x550x325 1150x660x450 1200x600x450 1500x800x500 2000x1000x400 Work Table mm 550x350 600x400 700x420 800x500 1000x600 1200x800 X Travel mm 300 350 450 500 800 1200 Y Travel mm 200 250 350 300 500 600 Z Travel mm 200 250 200+200 250 250 400 Max Job Weight kg 305 510 610 2050 3550 4555 Max Job Length mm 275 325 610 400 400 600
