Black Digital Batch Counter

DIGITAL BATCH COUNTER -
MODEL
1) BC - 9611
Size - 96x96x50 mm
Display - Upper : 7 segment, 6 digit, 0.56", RED LED display-Total Count
Lower : 7 segment, 4 digit, 0.4", GREEN LED display-Batch Count
Range - Upper display : range (0-999999 COUNT)
Lower Display range (0-9999)
2) BC - 7211
Size - 72x72x85 mm
Display - Upper : 7 segment, 6 digit, 0.4, RED LED display-Total Count
Lower : 7 segment, 4 digit, 0.4", GREEN LED display-Batch Count
Range - Upper display : range (0-999999 COUNT)
Lower Display range (0-9999)
3) BC- 4811
Size - 48x48x95 mm
Display - Upper : 7 segment, 4 digit, 0.3, RED LED display-Total Count
Lower : 7 segment, 4 digit, 0.3, GREEN LED display-Batch Count
Range - Upper display : range (0-99999 COUNT)
Lower Display range (0-9999)
INPUT -
Input Signal - NPN / PNP Proximity switch / Micro switch /(Configurable) / 230V AC Pulse (Factory Set)
OUTPUT -
Control Output - 1 - Relay (1 C/O, 5A, 230V AC) + Buzzer
SPECIFICATION -
Set Point - Set 1 & Set 2 (Configurable) (Optional)
Auto Time - 99.9 sec (Configurable)
Reset Facility - Auto / Manual Reset facility & Front & Back Reset Available
Power Supply - 230V AC 10%, 50 Hz (linear power supply)
Indication - LED for Relay Status Indication
Enclosure Material - Plastic
Operating Ambient Temp - 0 C to 55 C
Relative Humidity - Upto 95% RH Non Condensing
