Digital Rpm Controller - Plastic, 96x96x50 Mm | Auto Control Mode, 230v Ac Power Supply, 9999 Rpm Test Range, Black Color, Ideal For Industrial And Laboratory Use

DIGITAL RPM CONTROLLER
MODEL
1) RC - 9611
Size - 96x96x50 mm
Display - Upper : 7 segment, 6 digit, 0.56", RED LED display - Meters

Lower : 7 segment, 4 digit, 0.4", GREEN LED display Meters Per Minute
2) RC - 7211
Size - 72x72x85 mm
Display - Upper : 7 segment, 6 digit, 0.4, RED LED display - Meters
Lower : 7 segment, 4 digit, 0.4", GREEN LED display Meters Per Minu
3) RC- 4811
Size - 48x48x95 mm
Display - Upper : 7 segment, 4 digit, 0.3, RED LED display - Meters
Lower : 7 segment, 4 digit, 0.3, GREEN LED display - Meter Per Minute
RANGE - 0 to 9999 or 999.9 RPM (Factory)
INPUT -
Input Signal - NPN / PNP Proximity switch (Configurable) / Encoder (Configurable)
OUTPUT -
Control Output - 1- Relay (2 C/O, 5A, 230V AC)
SPECIFICATION -
Set Point - Single Set Point
Auto Time - 99.9 sec
Reset Facility - Auto / Manual Reset facility & Front & Back Reset Available
Power Supply - 230V AC 10%, 50 Hz (linear power supply)
Indication - LED for Relay Status Indication
Enclosure Material - Plastic
Operating Ambient Temp - 0 C to 55 C
Relative Humidity - Upto 95% RH Non Condensing
