Diac Characteristics - Fr-4 Glass Epoxy Pcb With 0-35v Variable Power Supply, V-i Graph Plotting Capabilities, Includes Socket And Patch Cards
Price:
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Edutek
In Stock
Product Specifications
| Components | Includes DIAC component, voltmeter, milliammeter, terminals, patch cords |
| Response Time | Immediate upon power-up |
| Interface | Panel terminals and analog meters |
| Operating Temperature | Room temperature - 0AdegC to 50AdegC |
| Power Supply | 230V AC, 50Hz |
| Features | Portable, easy to operate, educational use |
| Power Source | AC mains |
| Display Type | Other, Analog meters |
| Resolution | Analog scale resolution as per meters used |
| Input | AC mains |
| IP Rating | IP20 |
| Output | Characteristic curve on voltmeter and milliammeter |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Product Type | DIAC Characteristics |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 230V AC |
| Supply Voltage | 230V AC |
| Size | Standard bench-top instrument |
| Dimension (L*W*H) | 300mm x 200mm x 120mm |
| Function | Shows DIAC voltage-current (V-I) characteristics |
| Color | Black panel with colored traces |
| Weight | Approx. 2 kg |
| Thickness | Standard cabinet build |
| Current Rating | Up to 10mA |
| Capacity | Suitable for education laboratory tests |
| Frequency | 50Hz |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
DIAC Characteristics
Objectives: To observe the forward and reverse bias V-I Characteristics of DIAC and plot the graph and to observe the break over voltage of DIAC.
This unit consists a variable power supply of 0-35V 300mA.
The Circuit layout is designed on FR-4 type Glass Epoxy PCB with masked copper track lines.
Provision with 2mm socket for proper connectivity.
Sets of 2mm patch cards and user manual is accompanied with this kit.
