Darlington Pair Amplifier - Application: Engineering Electronics Instruments
Price: 1200.00 INR / Piece
(1200.0 INR + 0% GST)
Get Latest Price
In Stock
Product Specifications
| Operating Temperature | 0C to +50C |
| Input | Audio signal (microvolts to millivolts) |
| Features | Easy to use, compact, breadboard compatible, high gain, educational purpose |
| Response Time | Immediate |
| Thermal Conductivity | Standard FR-4 PCB |
| IP Rating | Not rated (indoor use only) |
| Output | Amplified audio signal |
| Power Source | DC Supply |
| Charging Voltage | Not rechargeable |
| Interface | Screw terminal, header pins |
| Color | Green PCB with black/blue connectors and components |
| Components | Transistors, resistors, capacitors, connectors, PCB |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Power Supply | External DC Supply |
| Product Type | DARLINGTON PAIR AMPLIFIER |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 12V DC |
| Supply Voltage | DC 9-12V |
| Size | Standard small PCB (approx. 55 mm x 26 mm) |
| Dimension (L*W*H) | 55 mm x 26 mm x 18 mm |
| Function | Amplifies weak input signals with high current gain |
| Weight | Approx. 60 grams |
| Thickness | 1.6 mm (PCB) |
| Current Rating | Max. output current up to 500 mA |
| Capacity | Single-channel amplification |
| Frequency | 20 Hz to 20 kHz |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
| Price Type | fixed |
| Returnable | No |
| Color | Green PCB with black/blue connectors and components |
| Currency | INR |
| Brand Name | EDUTEK |
| GSTIN | 0% |
Product Overview
Key Features
DARLINGTON PAIR AMPLIFIER
The board consists of the following built-in parts:
24V D.C. at 600mA, IC regulated Power Supply internally connected.
Transistors, fitted on adequate heat sinks.
Adequate no. of other electronic components.
Mains ON/OFF switch, Fuse and Jewel light.
The unit is operative on 230V 10% at 50Hz A.C.
