Cylinder Lock Cycles Test Machine - Color: Blue

Function:
Designed in accordance with ANSI/BHMA A156.5 and EN 1303 standards. The equipment precisely controls key rotation angle, torque, speed, and force via a servo motor. A variable rotation center coupling prevents misalignment and wear. A constant torque load of 3 in.-lbf (0.34 Nm) is applied at the cam end using a magnetic brake per ANSI/BHMA A156.5.
The touch screen allows for setting test parameters. The system stops automatically if torque or push/pull force exceeds the set value.

Equipment Parameters:

Model: ZNBHMA-3C
Framework: Aluminum profile test bench
Dimensions: L 0.8 m A W 0.6 m A H 1.2 m
Test Station: One or two stations
Operating Angle: 360A (settable)
Sensors: Cam position, key insertion position, push/pull force
Control System: Panasonic PLC for test setup, monitoring, and shutdown
Standards: ANSI/BHMA A156.5 clause 6.4 and EN 1303 clause 5.8
HMI: Winview (parameter setting, cycle display)
Pneumatics: AIRTAC
Mounting Bases:
Lock Cylinder Base: For European profile cylinders
Padlock Clamp Base: For padlocks under 80mm wide, key way at bottom
