Cold Press - 2700x1400 Mm Platen, 450-600 Ton Capacity | No Oil Leakage, Low Maintenance, Advanced Hydraulic & Electric Systems

Following are the Main Features of Cold Press :-
1. The machine is used for Pre-pressing process of making plywood, blockboard and decorative board.
2. The whole structure is designed and manufactured elaborately based on advanced international experience and new technological requirements.
3. The electric system and hydraulic system of the machine have been examined precisely and the free-beam will not fall by its own gravity with results assuring excellent quality.
4. The cylinders are made of super-hard metal(plunger hardness above HRC55),and sealed with low-resistance stepped gaskets,giving no oil-leakage,long service life and low maintenance cost.
5. Chain transmission is adopted for the feeding and discharging mechanisms,causing no damage to the plate bland,and thus it is recommended for the production line of decorative veneer boards.
01 Platen Dimension (MmA Mm) 2700A 1400
02 Nominal Gross Pressure (Tons)450i 600i
03 Normal Oil Pressure (Mpa) 28
04 Main Cylinder (Mm) I 320A 2
05 Minor Cylinder (Mm) I 80A 2
06 Opening Limit(Mm) 300-1200
07 Stroke Of Cylinder (Mm) 900
08 Hydraulic Center Motor (KwA P) 7.5A 4i 15A 4i
Power Transferring Motor (KwA P) 2.2A 4
09 Overall Dimensions (MmlA MmwA Mmh) 3860A 2200A 4900
10 Net Weight (Tons) 15.5
