Co2 Incubator - Application: Scientific & Laboratory Instruments

Carbon dioxide (CO2) incubators provide optimal growing conditions and contamination prevention for valuable cell cultures.
EDUTEK provides a wide range of CO2 incubators, ranging from a small capacity and volume to a large-scale capacity cabinet. All the
CO2 incubators are built with the patented Water Jacket and Air Jacket systems, which minimizes the risk of condensation at the present and in the future.
Water tank for humidity in the chamber.
Air jacket: Equipped with UV Lamp for sterilizing.
Water jacket: equipped with HEPA filter.
Equipped with USB port and LCD Display, the incubator can save data in real time.
High quality CO2 gas filter ensures the inside gas quality.
SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas.
Microcomputer controller, LED displays temperature, CO2 concentration, run-time and timing.
High quality infrared sensor for accurate CO2 concentration.
The working chamber adopts round angle structure, easy to clean.
Capacity: 160L
Heating: Air Jacket, Water Jacket
Temp. Range: RT +5 60C
Control Type: Microcomputer Controller
Temp. Fluctuation: < 0.2C (at 37C)
Temp. Uniformity: < 0.2C (at 37C)
Time Setting: 999h or Continuous
Alarm: Audible & Visible Alarm; Over Temp. alarm; CO2 Concentration alarm
Shelves: 2 pcs/ Adjustable
Material: External cold-rolled steel with painting: Internal Stainless-steel
Door: With Inner door & External door
CO2 Range: Infrared sensor, range 0-20%
CO2 Control Resolution: 0.10%
Humidification Type: Water Tank for normal evaporation
Sterilization Type: UV Lamp for Air jacket
Ambient Temp. & Humidity: 18-30C, Suggest 2 2C; Relative humidity < 80%
Caster: Footmaster caster
Consumption: 650W, 1000W
Power Supply: AC 110/220V 10%, 50/60Hz
Air Jacket:
Internal Size (WXDXH)mm: 498x546x678
External Size (WXDXH)mm: 700x666x1101
Packing Size (WXDXH)mm: 790x830x1250
Gross Weight(kg): 109
Water Jacket:
Internal Size (WXDXH)mm: 498x480x722
External Size (WXDXH)mm: 747x654x1260
Packing Size (WXDXH)mm: 780x880x1420
