Cnc Cutting Machine For Angle By Tai'an Falcon Cnc Machine Co., Ltd.

CNC Cutting Machine for Angle is a broadly used productive machine for processing angles from raw materials to finished products in one production run. It is designed for light Steel Tower structure fabricators. It is combined with CNC carriage for feeding, double punching station with 2 punching units each side, marking unit, double-blade cutting system and unloading unit. High speed processing and accurate position guarantee the machining quality and efficiency.

FMCSOFT, which locates in Park, Qingdao city, designed specialized software for TAL2020, which can read (*.dxf drawings) and (X-Steel: *.dstv) directly, also support manual (increasement) input.

Profile Specification
Steel Angle Material (ASTM) Min. mm Max. mm
A36 60 x 50 x 4mm 200x 200 x 20mm
Grade 50 60 x 50 x 4mm 200 x 200 x 20mm
Length of Angel Max. m 14

Cutting Capacity
Nominal Cutting Force KN 1540
Max. Cutting Thickness Mm 20
