Anti Tracking Tubes - Cross Linked Polyolefin, Various Diameters, Red | Heat Shrinkable, Anti-tracking, Flame Retardant, Uv Resistant, Chemical And Corrosion Resistant
Price:
Get Latest Price
In Stock
Product Specifications
| Application | Medium voltage cable joints |
| Color | Red |
| Diameter | Various |
| Features | Easy to wrap, Long life, Excellent heat isolation, Anti-tracking, Erosion resistance, Hologen free, Flame retardant, Weather resistance, UV resistance, Chemical resistance, Solvent resistance, Corrosion resistance, Fungus resistance |
| Material | Cross linked polyolefin |
| Product type | Heat shrinkable tubes |
| Shape | Tube |
Product Overview
Key Features
Anti-Tracking Tube
The provided Anti-Tracking Tubes are efficiently manufactured and supplied in a wide range to our valuable customers. The offered tubes are manufactured by utilizing optimum grade materials with the help of sophisticated techniques in accordance with the current market standards. These tubes are widely used in various industries like pharmaceutical, chemical, oil and others for wrapping the transmission tubes to avoid excessive heat emission related problems. Furthermore, clients can avail these Anti-Tracking Tubes from us at affordable prices.
Features:
- Easy to wrap
- Long life
- Excellent heat isolation
Heat Shrink Non Tracking Tubes are Used In Medium Voltage Cable Joints and terminations upto 36 KV. The tubes are produced from high quality non tracking cross linked polyolefin material that offers exceptional insulation and long term service reliability.
Excellent anti - tracking performance and erosion resistance.
Hologen free, flame retardant.
Good Weather / UV resistance.
High resistance to chemical, solvent, corrosion and fungus.
| Code | D Min. (mm) | d Max. (mm) | T10% (mm) | Spool length (mtr) |
| SIAT25/8 | 25 | 8 | 2.5 | 30 |
| SIAT 30/12 | 30 | 12 | 2.5 | 30 |
| SIAT 40/16 | 40 | 16 | 3.0 | 30 |
| SIAT 50/20 | 50 | 20 | 3.0 | 30 |
| SIAT 65/25 | 65 | 25 | 3.0 | 15 |
| SIAT 75/28 | 75 | 28 | 3.0 | 15 |
| SIHW 100/38 | 100 | 38 | 3.0 | 15 |
SELECTION CHART (Heavy Wall)
| Code | D Min. | d Max. | T10% | Length Max. |
| SIAT (HW) 25/8 | 25 | 8 | 5 | 1.5 |
| SIAT (HW) 35/12 | 35 | 12 | 5 | 1.5 |
| SIAT (HW) 55/18 | 55 | 18 | 5 | 1.5 |
| SIAT (HW) 65/25 | 65 | 25 | 5 | 1.5 |
| SIAT (HW) 85/30 | 85 | 30 | 5 | 1.5 |
| SIAT (HW) 100/38 | 100 | 38 | 5 | 1.5 |
| SIAT (HW) 120/45 | 120 | 45 | 5 | 1.5 |
| SIAT (HW) 140/50 | 140 | 50 | 5 | 1.5 |
SELECTION CHART (Extra Heavy Wall)
| Code | D Min. | d Max. | T10% | Length Max. |
| SIAT (EHW) 35/12 | 35 | 12 | 7 | 1.5 |
| SIAT (EHW) 55/18 | 55 | 18 | 7 | 1.5 |
| SIAT (EHW) 65/25 | 65 | 25 | 7 | 1.5 |
| SIAT (EHW) 85/30 | 85 | 30 | 7 | 1.5 |
| SIAT (EHW) 100/38 | 100 | 38 | 7 | 1.5 |
| SIAT (WHW) 120/45 | 120 | 45 | 7 | 1. |
TECHNICAL SPECIFICATION
| PROPERTIES | VALUE | STANDARD |
| Physical |
|
|
| Tensile Strength | 10 N/mm2(MPA)(min) | ASTM D638 |
| Ultimate Elongation | 350% (Min.) | ASTM D638 |
| Longitudinal Change | -10 % (max.) | ASTM D2671 |
| Density | 1.20 0.2 gm/cm3 | ASTM D792 |
| Hardness | 45 10 Shore D | ASTM D2240 |
| Water Absorption | 0.5 % (max.) | ASTM D570 |
| Thermal |
|
|
| Accelerated Ageing | (120oC for 500 Hrs) | ASTM D2671 |
| Tensile Strength | 8 N/mm2(Mpa) (min.) | ASTM D 638 |
| Ultimate Elongation | 250% (Min.) | ASTM D 638 |
| Low temperature Flexibility | No Cracking | ASTM D2671 |
| Heat Shock (250oC for 30 Min.) | No Cracking or flowing | ESI 09-11 |
| Shrink Temperature | 125C | IEC 216 |
| Continuous Temperature limit | -40C to + 100C | IEC 216 |
| Electrical |
|
|
| Dielectric Strength | 15 KV/mm. (Min.) | ASTM D149 |
| Volume Resistivity | 1 x 1014Ohm.cm(min.) | ASTM D257 |
| Dielectric Constant | 5 (Max.) | ASTM D150 |
| Resistant to track and erosion | No tracking,erosion or flame failure upto 3.25 | ASTM D2303 |
