Vertical Air Heater
Share

Vertical Air Heater

Price:

Get Latest Price

In Stock

In Stock

Product Specifications

Product TypeAir Heater
Grate Area0.8-3.6 Sq.M
Coal Capacity40-340 Kgs
Heat Generation2.5-15 Lacs
Max Heat3-20.6 Lacs
Overall DimensionsVaries
Tube MaterialAlloy Steel
FeaturesOptimum Transfer, Fuel Reduction, Easy Cleaning, Minimal Maintenance, Faster Installation, Compact Design, Multi Fuel

Product Overview

Key Features


T&I Global Limited (TIGL) presents BLAZE, the truly energy efficient special alloy vertical tube bank air heater, specifically designed for low firing costs and minimum maintenance. Indigenously developed, BLAZE is the only heater made of fully fabricated High Alloy Steel tube banks, refractory brick arches and combustion chambers, thus eliminating castings and improving thermal efficiency.



Operating Principle
:

Flue gases drawn by an induced draught created over the grate by the ID fan and chimney, passes at critical velocities through a set of vertical tubes placed on either side of the grate, and this ensures optimum heat transfer in each pass. Ambient fresh air drawn from the back of the heater

Salient Features & Advantages:

-

  • Optimum heat transfer due to the unique 'high temperature resistant' SS and alloy steel tube bank combination
  • Improved tube bank design and optimum fuel combustion rates ensure at least 15-20% reduction in fuel consumption
  • Vertical design ensures less scale/soot formation inside the tubes and enables easy cleaning
  • Minimal recurring maintenance cost since all parts are fully fabricated with heavy duty steel
  • Unique construction ensures easy and faster installation while reducing down time
  • Temperature control Unit for maintaining uniform temperature to dryer
  • Compact design for optimum floor space economy
  • Suitable for all dryers (Conventional , VFBD, Combination)
  • Truly multi fuel, can be operated with solid fuels like coal, leco, firewood, briquettes, bagasse, etc
  • No replacement of CI arches and other castings
  • Four Pass and Five Pass versions available.

Specifications:

































































ModelBLAZE 50BLAZE 100BLAZE 125BLAZE 200BLAZE 250BLAZE 350
Grate Area0.8 sq.m1.0 Sq. M1.2 Sq. M2.1 Sq. M2.6 Sq. M3.6 Sq.m
Coal burning capacity/hour40-50 Kgs80-100 Kgs120-160 Kgs200-250 Kgs260-310 Kgs270-340 Kgs
Heat generation capacity/
hour using Chain Grate Stoker
2.5 lacs Kcal5.00 Lacs Kcal7.00 Lacs Kcal11.00 Lacs Kcal13.00 lacs Kcal15.00 lacs Kcal
Max. heat generation
capacity /hour
3 Lacs Kcal6.00 Lacs Kcal9.60 Lacs Kcal15.00 Lacs Kcal18.60 Lacs Kcal20.6 Lacs Kcal
Overall Dimensions (LxWxH)3200 x 2650 x 25105770x3930x25106270x3930x25107380x4530x25108010x4530x25108800 x 5600 x 2510


Note:- Due to a continuous process of development the design is subject to change without notice.
