Kaizen Super Ctc Machine

Specially designed for larger factories, TIGLa s mega CTC machine is available in 48a & 52a for higher outputs, greater power saving and space economy. Kaizen SUPER also facilitates on-line matching with high output driers.

Salient Features & Advantages:

Wide Body CTC Machine : Kaizen Super CTC is available in 48" & 52 for enhanced operational economy without compromising on quality of cut. It facilitates high capacity on-line production (with matching capacity CFM and dryer) and leads to substantial savings on power (10% on CTC itself), fuel, man-power and maintenance costs.
Heavy Duty Construction : Kaizen Super is fitted with heavier cutting unit side plates having increased base width and higher dynamic load bearing capacity main bearings. The shaft diameter is also increased.
Centralised Lubrication System (Optional) : Kaizen Super is the first CTC machine built with a Centralised Lubrication System. This system applies optimum quantity of lubrication to each lubricating point of the machine from a single operating point. Timely and better lubrication ensures less wear & tear of moving components.
Dynamically balanced rollers and pulleys: Ensures vibration free operation as well as enhanced machine life. Vibration free operation ensures better cut and reduced motor load.
Improved Cutting Unit Cover Design : Kaizen Super introduces a unique centre hinged swing arm moving cover design with eccentric cam arrangement. This aids in easy roller changing and inspection of meshing. Eccentric cam arrangement ensures uniform tensioning and better belt tracking.
Belt Tracking Rollers : An in-built mechanism ensures self alignment of conveyor belts.
Roller Interchangeability : This increases the sharpening life and flexibility
Cooling Arrangement : Cold air introduced from behind the rollers prevents leaf temperature from rising, thereby improving the quality of tea.
Safety Guards : Specially designed international standard safety guards are provided over all moving parts. Tefloncoating is used for hygiene. Safety switches are used for high RPM areas. (Optional)
Superior Gear Box: Kaizen Super comes with a specially designed induction hardened gear box with large diameter input/output shafts. This ensures vibration free operation and also enhances the gear box and adaptor life. Comes with a 5 year guarantee!
Almost Zero Spillage : The reduced slope of conveyors, inclined side plates and full length skid plates help to eliminate ball formation and roll back, thereby reducing spillage substantially.
Bearing Sleeves : Hardened and ground bearing sleeves are provided on the mandrel bearing journals to ensure minimum damage to bearings.
Mandrel Adaptors : These are made of SG iron which has higher impact strength as well as higher corrosion resistance.
Easy & Fast Roller Removal : The Kaizen Super design eliminates top arm removal during roller change. The design incorporates single piece housing with larger contact area with side plate and top arm. The unique roller withdrawal mechanism makes removal of rollers convenient and quick.
Banded Multi V Belts: Kaizen Super uses new generation banded V belts which are high tensile steel wire braids. Power loss during transmission is minimal due to better design and traction, ensuring a power saving of 12-15% Rollers over conventional V belts. (Under development)

Specifications:



body,div,table,thead,tbody,tfoot,tr,th,td,p { font-family:"Liberation Sans"; font-size:x-small }
a.comment-indicator:hover + comment { background:#ffd; position:absolute; display:block; border:1px solid black; padding:0.5em; }
a.comment-indicator { background:red; display:inline-block; border:1px solid black; width:0.5em; height:0.5em; }
comment { display:none; }








Machine
Model
KS-120
KS-130


Size
48"
52"


Power HP*13" Dia roller
1st CutSubsequent Cuts
4030
4030


Rated Output*13" Dia roller
W. Leaf (Kgs/hr)
1600
1750


Segments13" Dia roller

OD - 330 mm
OD - 270 mm


Overall Dimension
Height (mm)Width (mm)
11582760
11582864


Length
Singlet4445, Duplex 6530, Triplex 8615, Quadruplex10700

* These are only recommendations subject to variations depending upon leaf quality and type of cuts. Due to continuous process of development the design is subject to change without noticeNote: Due to a continuous process of development the design is subject to change without notice.
