Valve Positioner (Ytc)

With the support of our expert, our company is dedicated Exporter, Distributor & Supplier of Valve Positioner (YTC) in Vadodara, Gujarat, India. YT-1000L Electro Pneumatic positioner is used for operation of pneumatic valve actuators by means of electrical controller or control system with an analog output signal of DC 4 to 20mA or split ranges.

i - It is designed for high durability and performance in high vibration environment.
i - Durability has proven after testing of 1 million times minimum.
i - Response time is very short and accurate.
i - Simple part change can set 1/2 Split Range.
i - It is economical due to less air-consumption.
i - Direct/Reverse action can be set easily.
- Zero & i Span adjustment process is simply.
- Feedback Connection is easy.

item type = single / double
input signal = DC 4 a 20 mA
Impedance = 250 +/- 15 a
Supply pressure = 1.4-7 kg(20-100pai)
stroke = 0-90*
air connection = PT(NPT) A
Gauge connection = PT(NPT)1/8
Conduit = PF A (G1/2)
Explosion proof = Ex dm |B T5
Ex dm |C T5
Ex ia |B T6
Protection = IP66
Ambient / operating = -20a c-70a c(-1 -158a F)
Temp explosion -20a c-60a c(-4 -140a F)
Linearity = +/- 1% F.S. | +/- 2% F.S.
Hysteresis = 1% F.S.
Sensitivity = +/- 0.2% F.S. | +/-0.5%F.S.
Repeatability = +/- 0.5%F.S.
Air consumption = 3LPM
Flow capacity = 8DLMP
Material = aluminium diecasting
Weight = 2.8 kg (6.2)
