Valve Hydro Testing Bench

Our Valve Hydro Testing Benches are available with following salient features :
1.Valve test bench
2.For gate/globe/check/ball/plug/control valves
3.Size1/2''~48''
4.Circulation water supply system


This valve test bench is used for make of hydraulic and pneumatic tests of swing check valves,according to the following:

1. Maximal clamping force : Depends on the valve max. pressure

2.Type of valves: Swing check valve, gate valve,globe valve, plug valve,ball valve,control valve

3.Size of valve : DN15-DN1200 ( Can be customized as per clients's tested valves)

4.Test bench is used for following operations:
- Shell test (strength test and hardness test) with water, maximum test pressure up to 700 bar (9975 psi) ;
- Shell test (strength test and hardness test) with air, maximum test pressure up to 6 bar (85 psi);
- Seat test (leakage test) with water of seat, gland seal and gasket joint, maximum test pressure up to 700 bar (9975 psi) ;
- Seat test (leakage test) with air, maximum test pressure up to 6 bar (85 psi).

5. Test bench makes testing of valve according to standards: API 598, DIN EN 12266, ISO 5208, ASTM E 1003 etc.

6. Type of valve connection: flange (Please specify type of connection valves according to each DN valve).

7. Size of test pressure:
- Body test (strength test and hardness test) with water: pressure test:1.5 times of body pressure
