Tubular Level Gauge - Borosilicate Glass Tube 16/19/25mm, 1600mm Length | Easy Installation, Zero Leakage, Visual Indication, Reliable Device

Our range of tubular level gauge are used for visual liquid level indication and is the most commonly used instrument in the process industry. These are simple and reliable device for level reading in atmospheric or pressurized tank applications. Our range is mounted parallel, along the side of the tank, so as to form a closed loop. When the process level fluctuates, the level in the transparent glass tube changes accordingly and gives local level indication.

Some of the features of our range includes:
* Tie rod or C-frame construction.
* Tie rod construction is 'light' and permits 360 C visibility.
* C-frame construction is robust and permits observation from front & rear.
* Both constructions are available in integral or in line arrangements.
* High quality, H grade borosilicate glass tube in 16/19/25mm outer diameter is used.
* Available in single length having c/c distance = 1600 mm. Extended lengths are provided by coupling several tubes or gauge assemblies in series.
* Gland packing design provides tension free tube installation to achieve zero leakage. It also enables glass removal for replacement or cleaning without dismantling the gauge or disconnection from the vessel.
* Transparent acrylic plate mounted on C-frame/acrylic pipe or slotted metallic pipe clamped on tie rod as glass protector can be provided if required, for additional safety to glass & personnel.
* Aluminum/SS scale with 5 mm resolution.
