Spectrometer By Mvtex Science Industries

We are exporting, manufacturing & supplying Spectrometer to our customers from Ambala cantt, Haryana, India.

Spectrometers
Three models, with following features in common. Difference noted against each model.

Base: A Heavy Cast iron base, with scratch resistance, oven-baked paint. Heaviness of base ensures stability.

Body: Streamlined to avoid cervices around fittings, where the paint could peel on the long run. Holding pillars for telescope and collimator of solid metal block to provide durability.

Scale: Main Scale, diameter 15cm, is divided 0-360 X A A , and fixed to a table that also holds the telescope. Two venires readings up to 1 minute of arc, located 180A apart at opposite sides of the main scale. Both venires visible through two protective, acrylic windows. Release of a clamping screw allows independent, rotation through fine adjustment screws for telescope and vernier scale. The scale and vernier have fine, granular finish for easy read ability.

Telescope: Mounted on a moveable pillar, with a fine adjustment screw, locking screw, axis adjustment. The achromatic objective is of focal length 17.8cm. Ramsden eyepiece 15 X with crossline graticule. With rack and pinion focussing for both objective and eyepiece.


Collimator: With achromatic objective of focal length 17.8cm. Rack and pinion focusing. Adjustable, 6mm slit is made of stainless steel.
