Smt Components Optical Inspection System Accuracy: 0.1 %

Having advanced resources and skills, we are engaged as manufacturer and exporter of SMT Components Optical Inspection System in Shenzhen, Guangdong, China available with following details.


Specifications:
Inspection System & Optical System
Inspection Object
Skew / Tombstone / Wrong part / Missing / Overturning / Damaged /
Cold joint / insufficient solder / Excess solder
Inspection Component
0402 chip , IC pin(0.3mm pitch), wave solder
Inspection Method
Full color image statistic analysis, OCP, IC bridge analysis, color linear analysis color non-linear analysis, similarity analysis, black-white ratio analysis, intensity analysis
Camera
Color CCD (1.45MPa Pixels), Resolution 20um, FOV 20*20mm (customized), speeda 2000mmA /s
Light Source
RGB Ring Multi-angle LED combination lighting, high brightness, standard CCTV lens, DOV 2mm
Software & Computer

Computer
CPU: Dual-core 2.7G, RAM: DDRIII-2G hard disk : 500G, 22" wide screen LCD
Mechanical System
PCB Thickness
0.3 - 5.0 PCB Warpage < 5mm
PCB Height
SMT : Top: 30mm, Bottom 45mm can be customized
Driving Method
AC Servo Motor+ball screw rod+linear guide rail
Motion Speed
Max 700mm/s
PCB Clamp
Automatic

Future:
1. HD image, easy for 0402 chip.
2. Full color image statistics analysis
3. Optical character recognition OCR
4. IC bridge analysis
5.Color analysis
6. Graphics similarity
7. Black white ratio analysis
8. Intensity analysis
