Single Phase 220v Frequency Converter Dimensions: 70 A 100 Centimeter (Cm)

We are offering our customers a wide range of Single Phase 220V Frequency Converter, which are available following Specifications :-
Place of Origin: Guang Dong, China (Mainland)
Brand Name: BroSea
Model Number: FWI-FI1-d75
Output Power: 0.75KW
Output Type: Single
Size: 139*90*110
Weight: 2.5KG
Input Voltage: 220V
Output Voltage: 0-220V
Type: AC/AC inverters
Output Frequency: 0--400HZ
Output Current: 4.5A
COLOR: black
Technical properties
FWI-FI UNIVERSAL VECTOR AND ENERGY SAVING SPECIAL TYPE / SPWM control
Overload capacity150% rated current 60S;180% rated current 10S;
Timing proportion 1:40
Frequency control precisionA 0.1%
Carrier frequency1.0K-15.0KHZ
Pure sine wave inverter
Functions and Features
High reliability with the motor control IC+IGBT at the core
A wider tolerance for the changes of supply voltage by A 15%
PID controller which is used in close loop control systems
Simple PLC which can achieve multi-speed, quasi winding and unwinding function, wobble, etc
High startup torque which can reach 150%while 1HZ
Good overload capacity which can reach 150% for 1 min, and 180% for 0.2 sec
Output frequency resolution can reach 0.01 HZ
Three user-defined frequency by passes and a range
Automatic compensate output torque when output frequency is low
Automatic regulate output voltage when supply voltage changes in range
Automatic energy-saving function which can automatic calculation the optimal output voltage according to the load to save energy.
